Description

Technical specifications

• Unladen mass
  4,640 kg
• Length
  11950 | 12,950 mm
• Width
  2,540 mm
• Height (* without extensions)
  2715 mm
• Load Capacity
  14,360 kg

• Detailed specifications

• Dimensions of the cargo box (height)
  1365 mm
• Dimensions of the cargo box (width)
  2,540 mm
• Dimensions of the cargo box (length)
  10,062 mm
• Suspension
  leaf springs
• Loading surface
  22.5 | 24.9 m2
• Floor sheet thickness
  4 mm
• Back and sideways tipping angle
  –
• Class of cooperating tractor
  100 KM
• Transport / working speed
  40 km / h
• Track of wheels
  1900 mm
• Tire type
  385/65 R22.5
• Height of floor from base
  1350 mm
• Cargo capacity
  – m3
