BRAND NEW ROUND BALE UNROLLER 2 IN 1 GTH-SIR FOR TRACTOR LOADER, TELEHANDLER, SKID STEER etc…. HEAVY DUTY!!! – HEAVY DUTY!!!
GTH-SIR Basic IV 1,2-1,6m model manual hydraulic connection in two side
THE PRICE IS COMPLETE WITH BRACKET FITTED READY TO YOUR LOADER AND HYDRAULIC HOSE – Just indicate the make and model of loader you want these to fit when ordering.
We can make these to fit most makes and models of tractor loaders (Quicke, Chiltern MF etc) and also telehandlers inc, JCB, Merlo,Cat, Bobcat, MF, Terex, Manitou etc
2-in-1 Straw bedder and bale unroller
This is the perfect machine for unrolling and shaking out bales of hay and haylage. Perfectly suited for drive-thru barns, henhouses, and even during mulching of strawberry plantations.
This is a distribution machine consisting of a bale unroller, shaker and frame with two tines 1100 mm in length for bale loading. It can be fastened to front loaders, telescopic loaders as well as to a three-point hitch. The bale is unrolled by means of two chains equipped with strips with dogs and shaken out even up to a range of 8m. The machine can additionally be equipped with automatic connection of hydraulic conduits, which accelerates work.
– Time savings: Direct bale loading by means of frame with tines and fast mulching.
– Resistance: High-quality Alform700 steel, subassemblies of renowned companies, powder painting.
– Universality: The bale-holding tines can serve for other tasks.
– Solid construction made of high-quality Alform700 steel with a thickness of 8mm.
– Fastening – to the spreader’s frame, enabling fast change of the fastening without cutting and welding.
– Automatic Connection of Hydraulic Conduits – option for additional charge £550+vat
– Hydraulic Conduits – resistance up to 330 bar.
– Spreading Distance – shaker position adjustment in 3 positions, spreading range from 1m to 8m.
– Hydraulic Feed – required: 40l min, 180 bar.
– Unrolling Speed – adjustment by means of potentiometer.
– Direction of shaking/unrolling – forward or right or left.
– Bale Unrolling – valve cutting off flow of hydraulic oil to the shaker, after which unrolling by itself is possible.
– Guarantee – 12 months.
– Other Dimensions – possibility of manufacturing spreader with dimensions according to the customer’s needs.
Technical specifications of GTH SIR
– Maximum Bale Dimension: height 1.2 m, diameter 1.6 m
– Weight – 500 kg
Made from High-Quality ALFORM 700 Steel
– Possibility of applying lower steel thickness while maintaining high strength.
– Thanks to its lower weight, it reduces fuel consumption and wear of the operational subassemblies of the machine to which the bale unroller is coupled.
– Higher resistance to mechanical impacts.
All machines sold by my company come from the European Union. The factory produces machines for over 20 years.
The machine has a 12 month manufacturer’s warranty.
